QuickServer Enhanced:

·      The QuickServer Enhanced offers all the rich benefits of the QuickServer BAS, but can accept up to 500 points, and comes complete with any two Serial or Ethernet drivers available from the extensive FieldServer Driver Library. RS-232 and RS-422 serial output options are also available on the QuickServer Enhanced.

·      FieldServer offers a powerful line of interpretable gateways, which offer a great amount of flexibility in choosing devises for your infrastructure.

·      QuickServer Enhance adds to that value by running the same robust FieldServer protocol conversion software on a highly cost effective platform.

·      The user can preselect two drivers (serial, Ethernet and/or LonWorks) to be loaded on the QuickServer Enhance.

·      QuickServer Enhance is ready to configure for the specific application. All necessary instructions and software are included with QuickServer Enhance.

   QuickServer Enhanced Key Features:

• Ability to interface up to 500 points of common BAS protocols
• BTL Mark - FS-QS-121X Series
• LonMark Certified - FS-QS-12X1 Series
• BACnet COV support for fast data communication while reducing traffic over a BACnet network

• Capacity of 500 LonWorks network variables - almost 5 times more than competition - FS-QS-12X1 Series
• RS-232 or RS-422 serial port options
• Multi-configuration capability; specific configurations selectable via DIP switches or software
• External DIP switches and LED lights to aid in easy set-up and operation

• Flat panel mount standard, DIN rail mount option
• DIP switches to select baud rate or node ID on the fly
